Beskrivning
Art.nr: 3EL1056011V2
Powering LiXX cells 2 - 3
RPM/V [ot./min/V] 1820
Turn count 20
Internal resistance [mOhm] 89
Open-circuit current [mA] 800
Max. efficiency [%] 84
Max. efficiency current (η>74%) [A] 8 - 12
Max. peak current (60 s) [A] 18
Max. power [W] 182
Diameter [mm] 27.7
Length [mm] 25.5
Shaft diameter [mm] 3.17
Weight [g] 43.5
Poles count 14
Timing [°] 15 - 25
ESC [A] 18 - 25
Weight of glider (up-to) [g] 500
Weight of trainer (up-to) [g] 450
Weight of acrobat (up-to) [g] 350
Weight of 3D (up-to) [g] 270
Doporučená vrtule 2S: 7,5x4", 8x3,8", 8x4"
Doporučená vrtule 3S: 7x4"
