AXI 5325/24 V2 brushless 232kv

Supply voltage LiXX cells: 8 - 10 ; RPM/V [RPM/min/V]: 232 ; Nr. of turns: 24 ; Internal resistance [mOhm]: 45 ; No load current [A]: 1.6 ; max. effenciency [%]: 92 ; Max. efficiency current (η>85%) [A]: 12 - 55 ; Max. peak current (60 s) [A]: 76 ; Max. power [W]: 2850 ; Diameter [mm]: 63 ; Lenght [mm]: 64.2 ; Shaft diameter [mm]: 8 ; Weight [g]: 595 ; Nr. of poles: 14 ; Timming [°]: 15 - 25 ; ESC [A] : 90 - 120 ; Sailplane up to Weight [g]: 10000 ; Trainer up to Weight [g]: 8000 ; Acrobat up to Weight [g]: 6000 ; 3d up to Weight [g]: 5000

Powering LiXX cells 8 - 10
RPM/V [ot./min/V] 232
Turn count 24
Internal resistance [mOhm] 45
Open-circuit current [A] 1.6
Max. efficiency [%] 92
Max. efficiency current (η>85%) [A] 12 - 55
Max. peak current (60 s) [A] 76
Max. power [W] 2850
Diameter [mm] 63
Length [mm] 64.2
Shaft diameter [mm] 8
Weight [g] 595
Poles count 14
Timing [°] 15 - 25
ESC [A] 90 - 120
Weight of glider (up-to) [g] 10000
Weight of trainer (up-to) [g] 8000
Weight of acrobat (up-to) [g] 6000
Weight of 3D (up-to) [g] 5000
Doporučená vrtule 10S: 19x12", 20x13"
