Spektrum Firma 2 in 1 Brushless Crawler Motor/ESC: 1400Kv
2 159 SEK
- Säkra kortbetalningar
- Fri frakt på ordrar över 2500kr
Beskrivning
Art.nr: SPMXSEM1040A
Product Details
The Spektrum Firma Sensored 2-in-1 System is specifically engineered to be used with 10th scale Crawlers and Scalers. Featuring advanced Field-orientated Control (FOC) and professional drag brake performance and torque control.
Key Features
Pro-level Drag Brake performance and adjustability
Compact for easy installation in most applications
Ready to install no soldering required
Integrated 40A / 160A ESC
Industry leading waterproof design
In The Box
(1) Spektrum Firma Brushless Sensored 2-in-1 System 1400Kv
(1) Product Manual
Needed to Complete
Spektrum Surface Receiver
2S or 3S LiPo Battery with EC3 or IC3 Connector
Spektrum Transmitter
Key Benefits
2-in-1 ESC Motor Combo: Compact option for detailed scale builds where space is limited
Advanced Sensored Motor Control: Great for slow speed driving and next level drag brake performance
Industry Leading Waterproof Design: The Firma 2-in-1 Brushless Crawler Motor/ESC provides industry leading waterproof and dustproof operation for worry-free driving in mud, sand, snow and water
Multi-point Protection:
Over-current protection
Automatic LiPo low-voltage cutoff
Thermal protection
Failsafe protection
Features
Pro-level Drag Brake performance and adjustability
RPM/Throttle Matching enabled
FOC (Field-Oriented Control) equipped
Integrated 40-amp ESC (160amp burst)
2-3S LiPo/6-9 Cell NiMH input voltage range
Industry Leading Waterproof Design
Fully programmable with optional Spektrum ESC Programmer Box (not included)
Developed and designed by Spektrum engineers, in partnership with the industry's leading ESC and Brushless Motor manufacturer
Compact for easy installation in most applications
Ready to install no soldering required
Adjustable high-power BEC (6V or 7.4V)
Firmware updatable through the Spektrum ESC Programming Box
High heat resistant IC3 connectors, backwards compatible with EC3 connectors
Limited 1-year warranty
The Ultimate Compact Crawler Solution
The Spektrum Firma Sensored 2-in-1 System is specifically engineered to be used with 10th scale Crawlers and Scalers. Featuring advanced Field-orientated Control (FOC) and professional drag brake performance and torque control, all while being fully waterproof.
The compact 2-in-1 design grants builders the ability to reduce clutter and components, giving you the most room for scale accessories and customization. The integrated design makes the size similar to a 550 can size motor, making it a easy drop-in option for most 1/10 scale crawler, scaler and trailer models.
Available in a low speed 1400Kv option for extreme slow speed and high angle of attack performance. And a high speed 2300Kv for excellent control for trailers and rock bouncers.
Product Specifications:
Connector Type: IC3
Forward: Yes
Reverse: Yes
Maximum Burst Current: 160A
Maximum Continuous Current: 40A
Motor Type: Brushless
Motor Size: 550-Size
Product Length: 2.28" (58 mm)
Programmable: Yes
BEC Voltage: 6V/7.4V adjustable, continuous current 4A (Switch mode)
Input Voltage: 2-3S Lipo, 6-9 Cells NiMH
Product Application: Crawling, Surface
RPM/Volt (Kv): 1400Kv
Sensored: Yes
Shaft Length: 0.62" (16 mm)
Application: 1/10 Rock Crawler
Auto Cutoff: Yes
Number of Poles: 4
Overload Protection: Yes
Product Weight: 201g (including wire plug)
Shaft Diameter: 0.125" (3 mm)
Water-Resistant: Yes
Outer Diameter: 1.45" (37 mm)
