Futaba Servo HPS-CT702 Bil Lågprofil 30kg 0.07s S.BUS/HV

Futaba HPS-CT702 – S.Bus2 High-Voltage Low-Profile Surface Servo
High-Performance Servo with Brushless Motor

FEATURES:

• Suitable for RC cars 1/10 scale on/off road and drifting
• Programmable/HV Brushless Servo
• Custom New high power Brushless Motor
• Supports SR mode (Super Response) with T4PM/T7PX/T10PX
• Programmable and compatible with S.Bus and S.Bus2 systems
• Can be connected to a PC using the CIU-2/-3 USB adapter sold separately.
• Upper/middle/bottom: Aluminum Case

Specs:

• Speed: 0.07sec/60° @ 7.4V / 0.08sec/60° @ 6V
• Torque: 30kg/cm @ 7.4V / 23kg/cm @ 6V
• Servo Size: Low profile Standard
• Dimensions: 40.5x21x26.2mm
• Weight: 53g
• Rated Voltage: 6-7.4V
• Operating Voltage: 4.8-8.4V

Längd: 40,5 mm
Bredd: 21 mm
Höjd: 26,2 mm
Vikt: 53 g
Max Drivspänning: 7,4 V
Hastighet vid 6,0V: 0,08 sek/60°
Hastighet vid 7,2/7,4V: 0,07 sek/60°
Styrka vid 6,0V: 23 kg/cm
Styrka vid 7,2/7,4V: 30 kg/cm
Egenskaper: Aluminiumhus , HV , S.Bus , S.Bus2
Levereras med: Servogummin, fästskruvar & servook
