Laddare iCharger X8 1100W 30A

X8 uses advanced Synchronous buck-boost DC/DC converter technology with high power, high current and high-performance power conversion circuit. The maximum charge power capacity is up to 1100W, the maximum charge/discharge current of a channel is up to 30A. X8 Supports 8s LiPo, Lilo, LiFe, LiHV, LTO and NiZn batteries, with maximum 2A balance current, and adopts a unique balance calculation of internal resistance correction. Supports 1-25s NiMH/NiCd batteries and 1-15s Pb batteries. With digital-power mode for great protection (over-current protection, over-voltage protection, input under-voltage protection, input undercurrent protection, and etc.) Intelligent fan control. Sensing internal temperature via the internal temperature sensor, to thereby control the fan speed. Internal temperature protection. When the internal temperature exceeds the Power Reduce temperature, the output power is automatically reduced: and the charger will shut down when temperature exceeds the Shut-down temperature. This charger can save 32 parameters sets and support the data import/export to SD card. A 2.4" IPS LCD screen provides rich information including current, voltage, power, capacity, internal resistance, control status, time-consuming and temperature, etc. Multi-discharge features: self-discharge, regenerative to input discharge, and lithium battery extra expanding discharge. Supports measurement for internal resistance of battery offline and online. Can measure not only the internal resistance of the entire battery pack, but also measure the internal resistance of each cell within the lithium battery. X8 has protection for reversed polarity (input or output), input voltage/current, battery temperature, charging capacity, overrun time and maximum power etc. Supports upgrading the hardware program by USB port or SD card. X8 also supports the “Junsi Console” software and can display, plot and analyze the charge and discharge data by it. EFLP1304E Charger X8 1100W 30A High Power Balance Charger (Portable size) Maximum Charge Power 1100W Charge Current Range 0.05-30A Discharge Current Range 0.05-30A Input Voltage 9-49V DC Input Current 35A Maximum Discharge 50W Maximum Regenerative Discharge 1100W Maximum External Discharge 1000W Current Drain For Balancing 2A Balance Accuracy 10mV LiPo/LiIo/LiFe 1-8S NiCd/NiMh Cell Count 1-20S Pb Battery Cell Count 1-12S Intelligent Temperature Control Yes PC Connectivity Micro USB Dimensions 98x65x37mm Weight 200g Includes: 1 x charger 2 x input cables 1 x CD disk for instruction manual &: software
