Spektrum Firma 2436 4500Kv 4-Pole Sensorless Brushless Motor: Minis

Product Details

Key Features
• Designed for the Losi Mini-T, Mini-B, Mini Drag, and Mini JRX2

In The Box
• (1) Spektrum Firma 2436 4500Kv 4-Pole Brushless Motor
• (1) Product Manual

Spektrum Firma 2436 4500Kv Motor Overview
The feature-packed Spektrum™ Firma™ 4500Kv Brushless Motor is a perfect option for 1/16 - 1/18 scale vehicles with a 2S-3S LiPo battery. It features a low-cog 4-pole rotor design, CNC machined aluminum housing, insulated high-purity copper windings, a high-quality alloy steel output shaft, and precision bearings for high durability and smooth rotation.

Spektrum Firma 2436 4500Kv Motor Features
• 2-3S LiPo power compatible
• Designed for efficiency
• 4-Pole sintered rotor
• Hardened steel output shaft
• Precision ball bearings

Product Specifications:
Application: 1/16 to 1/18th scale mini sized vehicles
Bushing Or Bearing: Bearing
Connector Type: 3.5mm Bullet
Input Voltage: 2-3S/12V
Motor Size: 2436
Motor Type: Brushless
Number of Poles: 4
Outer Diameter: 0.95" (24 mm)
Product Length: 1.38" (35 mm)
Product Weight: 61g (2.15oz)
RPM/Volt (Kv): 4500Kv
Shaft Diameter: 0.08" (2 mm)
Shaft Length: 0.47" (12 mm)
