Seagull Zivko Edge 540 V3 3D 231cm 60-70cc Gas ARF
11 556,25 SEK
- Säkra kortbetalningar
- Fri frakt på ordrar över 2500kr
Beskrivning
Art.nr: SEA363
Seagull SEA363 - Zivko Edge 540 V3 3D - 231cm wingspan - 60-70cc Gas
The Zivko Edge 540 V3 - 2310mm wingspan 60-70cc was designed with the intermediate/advanced sport flyer in mind. It is a semi scale airplane which is easy to fly and quick to assemble. The airframe is conventionally built using balsa, plywood to make it stronger than the average ARTF, yet the design allows the airplane to be kept light. You will find that most of the work has been done for you already. The motor mount has been fitted and the hinges are pre-installed.
Specifications:
Wingspan: 2310mm
Wing Area: 95.6sq/dm
Fuselage length: 2365mm
Weight: 8.8-9.2kg
Engine Required: 60-70cc Gas
Radio Required: 6 channels with 6 servos
Minimum servo specs:
Torque:
27.3 kg-cm @ 6.0V
33.7 kg-cm @ 7.4V
38.2 kg-cm @ 8.4V
Transit Speed:
0.14 sec/60° @ 6.0V
0.11 sec/60° @ 7.4V
0.10 sec/60° @ 8.4V
TOOLS & SUPPLIES NEEDED:
Thin cyanoacrylate glue
Medium cyanoacrylate glue
30 minute epoxy
5 minute epoxy
Hand or electric drill
Assorted drill bits
Modelling knife
Straight edge ruler
2mm ball driver
Phillips head screwdriver
220 grit sandpaper
90° square or builders triangle
Wire cutters
Masking tape & T-pins
Thread-lock
Paper towels
Driftsätt: Bränsle
Levereras som: Almost-Ready-To-Fly
Lämplig för: Erfaren , Expert
Plantyp: Aerobatic , Sport
Spännvidd: 2310 mm
Vingarea: 95,6 dm2
Längd: 2365 mm
Material: Trä
Vikt: 8800-9200 g
Sändare: Ingår Ej
Motor: Ingår Ej
Skevroder: Ja
Behöver kompletteras med: 6st Servon , Bensinmotor 60-70cc , Sändare & Mottagare
