XL Power Protos 380 STD V2 kit - red
4 035,28 SEK
- Säkra kortbetalningar
- Fri frakt på ordrar över 2500kr
Beskrivning
Art.nr: MSH41514
A builders kit of a high-performance 380-class 3D helicopter with 120° CCPM swashplate and flybarless main rotor for 325380 mm blades for 28xx32xx brushless motor and 6S LiPo. Contents: a complete set of the mechanic/airframe parts, tail rotor blades and manual; not included: brushless motor, electronic equipment, main rotor blades.
The Protos 380STD V2 is a high-performance 380-class electric-powered RC helicopter that can adopt a wide range of brushless motors and electronics; therefore - either straight out of the box or with optional parts added - it will meet the requirements of a beginner pilot as well as a seasoned 3D pilot and it is ready to work with their favourite and well-tested equipment. Many design concepts from the Protos 700 Maxx V2 have been downsized and included in the Protos 380, such as the Gorilla undercarriage, external belt tensioner, double belt style transmission or magnetic canopy mounting system. Other updates: new frames provide different servo geometry and weight bias towards the front of the heli for improved CG; large ESC compartment, the latest rigid tail blades are included providing better tail performance and control authority under demanding 3D flight.
Protos 380STD V2 Features:
Flybarless main rotor head
120° CCPM swash plate
Rigid airframe with 1.5mm carbon sides
Double Belt Style Transmission
For 2025T pinions (3.5 or 5mm motor shaft); 22T pinion in the kit
Main pulley 120T, autorotation pulley 94T, tail pulley 22T (21T optional)
Suitable for 325380mm main rotor blades
External Tail Belt Tensioner
Mini and Micro Tail Servo Mounting Options
Large ESC compartment
67mm tail rotor blades supplied in the kit
Front/Rear load battery tray
Magnetic canopy holders
Elegant canopy
Durable composite Gorilla undercarriage
Recommended main rotor blades: 325380 mm carbon.
Recommended RC set: At least 6-channel computer transmitter w. heli program.
Recommended cyclic servos: Micro size (23 mm case length), like MKS HV93, DS95, KAVAN GO-1020MG, GO-1021MG
Recommended tail servo: Micro size (23 mm case length), like MKS HV93i, DS95i, KAVAN GO-1021MG or Mini size (35 mm case length) - like MKS HV9780, KAVAN GO-11T46MG, Futaba S9257.
Flybarless control unit: Futaba CGY760R, CGY755, Bavarian Demon BD 3X, BD AXON, etc.
Suitable motor: 28xx, 30xx, 32xx size brushless outrunner (Ø5 mm shaft) 8001000KV for 6S LiPo. Like XL Power XL3215 920KV for 6S LiPo or similar.
ESC suitable for sport flying: 5070A heli brushless ESC, like Hobbywing Platinum PRO 60A V4 or similar.
ESC suitable for 3D and extreme 3D flying: 8090A heli brushless ESC, like Hobbywing Platinum 80A V4 or similar.
Flight pack: 6S LiPo 18002200 mAh min. 60C, battery compartment dimensions 115×40×35 mm.
The kit contents: The complete set of the mechanic/airframe parts, tail rotor blades and manual; not included: main rotor blades, brushless motor and electronics.
Main rotor diameter (s 380 mm listy) [mm] 864
Tail rotor diameter (se 67 mm listy) [mm] 181
Length trupu [mm] 800
Width [mm] 110
Height [mm] 235
Weight (orientační letová) [g] 1300
Controlled functions M,Kl,Ko,Kp,Vr,gyro
Build difficulty S2,S3
Operating difficulty P3,P4
