Beskrivning
Art.nr: 553001
: Nya 330X-S är baserad på UAV maskiner som Gaui har utvecklad. DEnna maskinen är utrustad med Scorpio elmotorer och special reglage med 400hz uppdateringshastighet som gör maskinen stabilare i luften. Kommer i komplett byggsats , du måste komplettera med driv ack och mottagare för ditt radiosystem. Flygvikt ca: 500-1100g beroende på ack och eventuel extra utrustning, max extra vikt upp till 700g, tom maskin väger ca 400g. GPS system kommer under hösten. Ack : 2s2100 till 3s2100mAh detta ger flygtider över 10 minuter, nedan har du effekt siffror för att se hur stor ack du behöver, inga problem att flyga 30mim men det blir mindre vikt över till extra utrustningen. Manual till 330X-s: : : : : : Flying Weight (g) : : Pay load (g) : : Power consumption (w) : : Efficiency value (g/w) : : : 500 : : 100g(2S2000mAh) : : 50 : : 10 : : : 550 : : 150g(3S2000mAh) : : 63 : : 8.73 : : : 600 : : 200 : : 75 : : 8 : : : 650 : : 250 : : 84 : : 7.7 : : : 700 : : 300 : : 92 : : 7.6 : : : 750 : : 350 : : 102 : : 7.4 : : : 800 : : 400 : : 111 : : 7.2 : : : 850 : : 450 : : 120 : : 7.1 : : : 900 : : 500 : : 130 : : 6.9 : : : 950 : : 550 : : 142 : : 6.7 : : : 1000 : : 600 : : 155 : : 6.5 : : : 1050 : : 650 : : 162 : : 6.5 : : : 1100 : : 700 : : 170 : : 6.5 : For example, while equipping 330X-S with a HD camera (350g), you would like to use a 3S2000mAh Lipo battery, so the total payload will be 500g (flying weight of 900g), And hovering consumption of power for 130w (see above) and your total battery charge for the 11.1X2 (A) X60 (min) = 1332 1332/130 = 10.2 (min) 10.2X75% (battery safety coefficient) = 7.7 (min) If you want to use two groups 3S2000mAh the Lipo battery, then your total payload of 650 (flying weight of 1050g), so the total charge for the 11.1X2 (A) X60 (min) X2 = 2662, but now hovering consumption power for the 162w so the flight time (2662/162) X75% = 12.3min : *The actual of Cruise data with full payload(The safety flight time: 1332/170X75%=5.88min) : : Flight Efficiency: Standard Battery (2S2000mAh) time of flight for more than 12min, with a high-capacity battery, the flight time will be more than 20 min or more (available spreadsheet calculation) : Excellent wind resistance: the efficiency and load of propeller are perfectly optimized, so the wind resistance will be better than general electric aircraft : H igh stability: contains GU344 (three-axis stabilizing system) for the beginner or the FPV flying, it is a very stable Vehicle : Additional payload capabilities: payload up to 700g (including battery), can freely install cameras and video recorder, and other general system : System Extensibility: can be used with GPS positioning system and navigation system on 330X-S without any change : Operation mode and flight characteristics are same as helicopter, but no complex transmission : C ollapsible body design, greatly reduce the damage rate, Which can be repaired easily without adjustment. : demo video:
