Beskrivning
Art.nr: 58037
KingTech G4 utilizes SBus data transmission.
Engine/ECU integration, all operating parameters including total run time are all recorded into the engine.
The smaller and lighter external Data Relay Module (DRM) is responsible for all data, signal and power transmission.
Pump: digital sbus brushless pump
A micro USB connector is present for a future connectivity of wireless mobile apps.
The G4 features a brushless starter motor for reliability and durability, built-in FOD screen is also integrated.
After a run cycle and receiver switched off, GSU will remain on only until cool down completes.
K-235G4 SPECIFICATIONS
Diameter: 119 mm
Length: 278 mm
Weight: 2.0 kg
Max. RPM:109,000
Thrust: 23.5 kg @ max RPM
EGT: 750°C max
Pump type: Digital sbus brushless pump (KP800BL)
Fuel consumption: 680 g / min
Fuel: Diesel, Jet A1, Kerosene
Lubrication: 5%
Pressure ratio: 3.7:1
Mass flow (kg/s): 0.46
Exhaust gas speed (km/h): 1839
SFC @ max Rpm (kg/Nh): 0.176
Engine/ECU integration, all operating parameters including total run time are all recorded into the engine.
The smaller and lighter external Data Relay Module (DRM) is responsible for all data, signal and power transmission.
Pump: digital sbus brushless pump
A micro USB connector is present for a future connectivity of wireless mobile apps.
The G4 features a brushless starter motor for reliability and durability, built-in FOD screen is also integrated.
After a run cycle and receiver switched off, GSU will remain on only until cool down completes.
K-235G4 SPECIFICATIONS
Diameter: 119 mm
Length: 278 mm
Weight: 2.0 kg
Max. RPM:109,000
Thrust: 23.5 kg @ max RPM
EGT: 750°C max
Pump type: Digital sbus brushless pump (KP800BL)
Fuel consumption: 680 g / min
Fuel: Diesel, Jet A1, Kerosene
Lubrication: 5%
Pressure ratio: 3.7:1
Mass flow (kg/s): 0.46
Exhaust gas speed (km/h): 1839
SFC @ max Rpm (kg/Nh): 0.176
