TOYAN ENGINE FS-V800GCS 8-Cyl Metanolmotor 4-Takt Byggsats

Toyan Engine TE800VGCS - FS-V800GCS 8-Cyl Methanol Engine 4-Stroke Kit

Long Stroke

• The cross crankshaft is the blueprint for the engine design, effectively providing higher torque. Customized flexible oil seal keeps sealing performance in high speed operation.

Mechanical Water Cooling Pump

• The power of the pump, come from the crankshaft, provides circulation power for the coolant liquid, and then in conjunction with the cooling fan to strengthen the self-cooling performance.

Intergrated processing crankshaft

• Adopt 90 degree cross crankshaft construction
• Runs more smoothl.
• Acceleration more responsive.
• Maximum speed up to 12,500rpm

Double synchronous belt pulley

• Double synchronous belt pulley timing structure.
• Greatly reduce the risk of gear jumping in high speed operation.

Precision carburetor

• New carburetor design.
• More accurate tuning.
• Makes the throttle response more sensitive and stable.

Intergrated exhaus pipe

• Makes the sound the engine more powerful

Specs

• Material: Metal
• Displacement:28cc (3,5cc x 8)
• Engine Weight: 2,05kg
• Cooling: Water cooling
• RPM range:1800-12500 RPM
• Piston Bore: 16,678mm
• Stroke: 17,0mm
• Power: 4,35ps
• Fuel:16% Nitro
